Where Do You Put Glazing Packers? A Step-by-Step Guide to using flat packers and shims

Where Do You Put Glazing Packers? A Step-by-Step Guide to using flat packers and shims

Glazing packer positions depend on the frame system, opening style and glass unit. Use the window or door manufacturer’s packing diagram: there is no single corner distance or packing pattern suitable for every installation.

Understand what each packer does

Setting blocks support the glass; location blocks maintain its position. Bridge packers provide a suitable platform where the system requires drainage beneath the glazing blocks. Frame shims used around fixings perform a different job.

Before positioning the glass

  • Identify the frame system and obtain its glazing instructions.
  • Confirm the specified packer material, width, length, thickness and load suitability.
  • Check that the glazing rebate and drainage paths are clear.
  • Use appropriate glass-handling equipment and competent help for the unit’s size and weight.

Follow the system’s packing sequence

  1. Check the frame is correctly installed before glazing.
  2. Fit the specified bridge or setting blocks at the positions shown in the manufacturer’s diagram.
  3. Support and position the glass using the specified procedure; prevent direct contact with the frame.
  4. Add location blocks where instructed, preserving the required clearances and drainage.
  5. Fit the beads and check the finished unit and opening operation according to the system instructions.

Fixed windows, opening sashes and doors differ

Do not automatically mirror bottom packers at the top or use a generic 100mm spacing. Toe-and-heeling arrangements for opening units must follow the relevant system diagram. Do not force extra packers into a tight gap or substitute soft foam for specified glazing blocks.

Choose dimensions before pack quantity

Packer width is not glass-unit thickness. Confirm the required support width and clearance before selecting a product. If the frame system or packing arrangement is unknown, ask the fabricator or a competent glazing installer before proceeding.

Choose flat packers for your specification

Compare 24mm, 28mm and 30mm widths. Width is not glass-unit thickness: follow your frame or glass supplier’s specification for the required size and placement.

24mm × 100mm flat packers

24mm × 100mm flat packers

Single-thickness or mixed 1–6mm options. Choose thickness and pack quantity.

Choose thickness & pack →

28mm × 100mm flat packers

28mm × 100mm flat packers

Single-thickness or mixed 1–6mm options. Choose thickness and pack quantity.

Choose thickness & pack →

30mm × 100mm flat packers

30mm × 100mm flat packers

Single-thickness or mixed 1–6mm options. Choose thickness and pack quantity.

Choose thickness & pack →

Product pages show current prices and availability. Check the required dimensions and compatibility before ordering.

Browse all flat packer widths · Compare bridge packers

Further reading: Glazpart’s installer guidance. Your own frame manufacturer’s instructions take precedence for your installation.
